COLORE INDICATORE CONDIZIONATO

• 03/07/2024 at 6:42 PM #229419
  druby

  Buon tentativo… ‘Colorbetween’ è un cliente ingannevole in questo caso.

  Non lo capisco ancora del tutto, ma posso usare abbastanza per portare a termine il lavoro per ora.

  Druby

  // constants period = 13 deviation1 = 1 deviation2 = 2 deviation3 = 3 up = 1 down = -1 begin = 1 null = 0 // (i) indicators iSTD1 = deviation1 * STD[period](close) iSTD2 = deviation2 * STD[period](close) iSTD3 = deviation3 * STD[period](close) iSMA = Average[period,0](close) // (c) conditions cUpperBand3 = iSMA + iSTD3 // ----3---- cUpperBand2 = iSMA + iSTD2 // ----2---- cUpperBand1 = iSMA + iSTD1 // ----1---- cMiddleBand = iSMA // ----0---- cLowerBand1 = iSMA - iSTD1 // ----1---- cLowerBand2 = iSMA - iSTD2 // ----2---- cLowerBand3 = iSMA - iSTD3 // ----3---- // delay start if begin = 1 and barindex < period then // hold off till enough bar present ts = undefined // removes ts tangent line from 0 til real value available else begin = 0 endif // logic operation // setup block --> When 'begin' = 0, executes next block. // Since 'trend' default = 0, being set to 1 or -1 will // allow the 'following' logic code blocks to be executed // Bollinger Logic ----------- // initial, set trend, trend only changed by iSTD1 if begin = null then if close crosses over cUpperband1 then trend = up elsif close crosses under cLowerBand1 then trend = down endif endif // following from first time after trend set! // change of trend, up --> down if trend = up and close crosses under cLowerBand1 then trend = down endif // change of trend, down --> up if trend = down and close crosses over cUpperBand1 then trend = up endif // set 'ts' values to appropriate band threshold level if trend = up then ts = cLowerBand1 elsif trend = down then ts = cUpperBand1 endif // drawing ============================================================================== // color settings if trend = up then r = 0 g = 255 a1 = 90 // on upperband 3 green a2 = 70 // on upperband 2 green a3 = 50 // on upperband 1 green a4 = 30 // on lowerband 1 green a5 = 0 // off upperBand 1 red a6 = 0 // off lowerBand 1 red a7 = 0 // off lowerBand 2 red a8 = 0 // off lowerBand 3 red elsif trend = down then r = 255 g = 0 a1 = 0 // off upperband 3 green a2 = 0 // off upperband 2 green a3 = 0 // off upperband 1 green a4 = 0 // off lowerband 1 green a5 = 30 // on upperBand 1 red a6 = 50 // on lowerBand 1 red a7 = 70 // on lowerBand 2 red a8 = 90 // on lowerBand 3 red endif // band colors - # turn of any conflicting 'colour zones' in 'config settings'!!! // green colorbetween(cUpperBand2,cUpperBand3, r,g,0,a1) // upperBand3 green - trend up colorbetween(cUpperBand1,cUpperBand2, r,g,0,a2) // upperBand2 green - trend up colorbetween(cMiddleBand,cUpperBand1, r,g,0,a3) // upperBand1 green - trend up colorbetween(cMiddleBand,cLowerBand1, r,g,0,a4) // lowerBand1 green - trend up // red colorbetween(cMiddleBand,cUpperBand1, r,g,0,a5) // upperBand1 red - trend down colorbetween(cMiddleBand,cLowerBand1, r,g,0,a6) // lowerBand1 red - trend down colorbetween(cLowerBand1,cLowerBand2, r,g,0,a7) // upperBand2 red - trend down colorbetween(cLowerBand2,cLowerBand3, r,g,0,a8) // upperBand3 red - trend down return ts coloured(r,g,50) style(line,1) as "dev", cMiddleBand coloured(r,g,50) style(dottedline,1)as "sma"

  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117

  // constants period = 13 deviation1 = 1 deviation2 = 2 deviation3 = 3 up = 1 down = -1 begin = 1 null = 0   // (i) indicators iSTD1 = deviation1 * STD[period](close) iSTD2 = deviation2 * STD[period](close) iSTD3 = deviation3 * STD[period](close) iSMA = Average[period,0](close)   // (c) conditions cUpperBand3  = iSMA + iSTD3  //          ----3---- cUpperBand2  = iSMA + iSTD2  //       ----2---- cUpperBand1  = iSMA + iSTD1  //    ----1---- cMiddleBand  = iSMA          // ----0---- cLowerBand1  = iSMA - iSTD1  //    ----1---- cLowerBand2  = iSMA - iSTD2  //       ----2---- cLowerBand3  = iSMA - iSTD3  //          ----3----   // delay start if begin = 1 and barindex < period then  // hold off till enough bar present ts = undefined  // removes ts tangent line from 0 til real value available else begin = 0 endif   // logic operation // setup block --> When 'begin' = 0,  executes next block. //                  Since 'trend' default = 0, being set to 1 or -1 will //                  allow the 'following' logic code blocks to be executed // Bollinger Logic ----------- // initial, set trend, trend only changed by iSTD1 if begin = null then if close crosses over cUpperband1 then trend = up elsif close crosses under cLowerBand1 then trend = down endif endif // following from first time after trend set! // change of trend,   up --> down if trend = up and close crosses under cLowerBand1 then trend = down endif // change of trend,   down --> up if trend = down and close crosses over cUpperBand1 then trend = up endif // set 'ts' values to appropriate band threshold level if trend = up then ts = cLowerBand1 elsif trend = down then ts = cUpperBand1 endif   // drawing  ==============================================================================   // color settings if trend = up then r = 0 g = 255   a1 = 90 // on   upperband 3 green a2 = 70 // on   upperband 2 green a3 = 50 // on   upperband 1 green a4 = 30 // on   lowerband 1 green   a5 = 0  // off  upperBand 1 red a6 = 0  // off  lowerBand 1 red a7 = 0  // off  lowerBand 2 red a8 = 0  // off  lowerBand 3 red   elsif trend = down then r = 255 g = 0   a1 = 0  // off upperband 3 green a2 = 0  // off upperband 2 green a3 = 0  // off upperband 1 green a4 = 0  // off lowerband 1 green   a5 = 30 // on  upperBand 1 red a6 = 50 // on  lowerBand 1 red a7 = 70 // on  lowerBand 2 red a8 = 90 // on  lowerBand 3 red endif     // band colors  - # turn of any conflicting 'colour zones' in 'config settings'!!!   // green colorbetween(cUpperBand2,cUpperBand3, r,g,0,a1)  // upperBand3 green - trend up colorbetween(cUpperBand1,cUpperBand2, r,g,0,a2)  // upperBand2 green - trend up colorbetween(cMiddleBand,cUpperBand1, r,g,0,a3)  // upperBand1 green - trend up colorbetween(cMiddleBand,cLowerBand1, r,g,0,a4)  // lowerBand1 green - trend up // red colorbetween(cMiddleBand,cUpperBand1, r,g,0,a5)  // upperBand1 red - trend down colorbetween(cMiddleBand,cLowerBand1, r,g,0,a6)  // lowerBand1 red - trend down colorbetween(cLowerBand1,cLowerBand2, r,g,0,a7)  // upperBand2 red - trend down colorbetween(cLowerBand2,cLowerBand3, r,g,0,a8)  // upperBand3 red - trend down     return ts coloured(r,g,50) style(line,1) as "dev", cMiddleBand coloured(r,g,50) style(dottedline,1)as "sma"







  1 user thanked author for this post.

  PaFM



  druby

  Participant

  Topics: 1

  Replies: 378

  Been thanked: 290 times
  03/07/2024 at 8:05 PM #229422
  druby

  ottimizzazione, funziona anche questo!



  // color settings if trend = up then r = 0 g = 255 // set all colorbetween's green a1 = 90 // on upperband 3 a2 = 70 // on upperband 2 a3 = 50 // on upperband 1 a4 = 30 // on lowerband 1 a5 = 0 // off lowerBand 2 a6 = 0 // off lowerBand 3 elsif trend = down then r = 255 // set all colorbetween's red g = 0 a1 = 0 // off upperband 3 a2 = 0 // off upperband 2 a3 = 30 // on upperBand 1 a4 = 50 // on lowerBand 1 a5 = 70 // on lowerBand 2 a6 = 90 // on lowerBand 3 endif colorbetween(cUpperBand2,cUpperBand3, r,g,0,a1) // upperBand3 green - trend up colorbetween(cUpperBand1,cUpperBand2, r,g,0,a2) // upperBand2 green - trend up colorbetween(cMiddleBand,cUpperBand1, r,g,0,a3) // upperBand1 green/red - trend up/down colorbetween(cMiddleBand,cLowerBand1, r,g,0,a4) // lowerBand1 green/red - trend up/down colorbetween(cLowerBand1,cLowerBand2, r,g,0,a5) // lowerBand2 red - trend down colorbetween(cLowerBand2,cLowerBand3, r,g,0,a6) // lowerBand3 red - trend down

  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

  // color settings   if trend = up then r = 0 g = 255  // set all colorbetween's green   a1 = 90  // on   upperband 3 a2 = 70  // on   upperband 2 a3 = 50  // on   upperband 1 a4 = 30  // on   lowerband 1   a5 = 0   // off  lowerBand 2 a6 = 0   // off  lowerBand 3   elsif trend = down then r = 255  // set all colorbetween's red g = 0   a1 = 0   // off   upperband 3 a2 = 0   // off   upperband 2   a3 = 30  // on  upperBand 1 a4 = 50  // on  lowerBand 1 a5 = 70  // on  lowerBand 2 a6 = 90  // on  lowerBand 3 endif   colorbetween(cUpperBand2,cUpperBand3, r,g,0,a1)  // upperBand3 green - trend up colorbetween(cUpperBand1,cUpperBand2, r,g,0,a2)  // upperBand2 green - trend up colorbetween(cMiddleBand,cUpperBand1, r,g,0,a3)  // upperBand1 green/red - trend up/down   colorbetween(cMiddleBand,cLowerBand1, r,g,0,a4)  // lowerBand1 green/red - trend up/down colorbetween(cLowerBand1,cLowerBand2, r,g,0,a5)  // lowerBand2 red - trend down colorbetween(cLowerBand2,cLowerBand3, r,g,0,a6)  // lowerBand3 red - trend down

  1 user thanked author for this post.

  PaFM



  druby

  Participant

  Topics: 1

  Replies: 378

  Been thanked: 290 times
  03/08/2024 at 3:34 AM #229430
  PaFM

  Great job Druby, thank you so much!!!

  Best

  PaFM



  PaFM

  Participant

  Topics: 3

  Replies: 16

  Been thanked: 0 times
• Author
  Posts
