Señalizar maximos y minimos relativos

• 04/11/2024 at 5:24 PM #231416
  lokbuscas

  Hola,

  estoy tratando de hacerlo pero no me señaliza lo que yo quiero y no se si es posible.
  Quiero dibujar un indicador que me señale con flechas en el grafico del precio los minimos y maximos relativos definiendolos de la siguiente manera:
  Maximo relativo = sería aquella vela cuyo maximo sea mayor a los maximos de las “n” velas anteriores y posteriores
  minimo relativo = sería aquella vela cuyo minimo sea menor a los minimos de las “n” velas anteriores y posteriores

  Gracias



  lokbuscas

  Participant

  Topics: 4

  Replies: 4

  Been thanked: 0 times
  04/12/2024 at 7:33 AM #231425
  Iván

  Hola
  Aquí tienes una forma de hacerlo:

  ////////pivothigh ph1 = high < high[prd] ph2 = highest[prd](high) < high[prd] ph3 = high[prd] > highest[prd](high)[prd+1] if ph1 and ph2 and ph3 then pivotH = high[prd] drawtext("▼",barindex[prd],high[prd])coloured("red") else pivotH = pivotH endif ////////pivotlow pl1 = low > low[prd] pl2 = lowest[prd](low) > low[prd] pl3 = low[prd] < lowest[prd](low)[prd+1] if pl1 and pl2 and pl3 then pivotL = low[prd] drawtext("▲",barindex[prd],low[prd])coloured("green") else pivotL = pivotL endif return //pivotH as "PivotHigh", pivotL as "PivotLow", lowest[prd](low) as "LLL" coloured("red")

  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

  ////////pivothigh ph1 = high < high[prd] ph2 = highest[prd](high) < high[prd] ph3 = high[prd] > highest[prd](high)[prd+1] if ph1 and ph2 and ph3 then pivotH = high[prd] drawtext("▼",barindex[prd],high[prd])coloured("red") else pivotH = pivotH endif   ////////pivotlow pl1 = low > low[prd] pl2 = lowest[prd](low) > low[prd] pl3 = low[prd] < lowest[prd](low)[prd+1]   if pl1 and pl2 and pl3 then pivotL = low[prd] drawtext("▲",barindex[prd],low[prd])coloured("green") else pivotL = pivotL endif   return //pivotH as "PivotHigh", pivotL as "PivotLow", lowest[prd](low) as "LLL" coloured("red")



  Iván

  Moderator

  Topics: 0

  Replies: 1359

  Been thanked: 504 times
  04/12/2024 at 7:35 AM #231426
  Iván

  Si prefieres cambiar los triángulos por las flechas cambia las líneas de dibujar texto drawtextpor drawarrowup y drawarrowdown



  Iván

  Moderator

  Topics: 0

  Replies: 1359

  Been thanked: 504 times
  04/12/2024 at 8:06 PM #231469
  lokbuscas

  Muchas gracias Iván funciona perfecto!!!!!!!
