traduzione codice TW order block

• 10/12/2023 at 9:41 AM #222321
  Msport71

  Buongiorno,

  volevo chiedere cortese traduzione del seguente codice da TW, che non troppo esteso sembra interessante.

  Grazie e mille.

  https://it.tradingview.com/script/i3BKmxdj/

  // This source code is subject to the terms of the Mozilla Public License 2.0 at https://mozilla.org/MPL/2.0/

  // © dadoesploso

  //@version=4

  study(title=”Volatility Expansion Levels”, shorttitle = “VEL”,overlay=true)

  atrc = input(defval=0.9, title=”ATR Multiplier (of Trapped Trend Bar minimum absolute close-to-open distance). Default is 0.9. Higher values make the indicator picky.”)

  atrct = input(defval=2.0, title=”Trapping Trend Bar Close-Open Minimum value (relative to Trapped Trend Bar absolute close-to-open distance). Default is 2. Higher values make the indicator picky.”)

  lenght = input(title=”Rectangle Lenght”, type=input.integer, defval=350)

  //Bullish VEL

  if (open[1] – close[1]) > atrc*atr(10) and close – open > atrct*(open[1] – close[1])

  box.new(left=bar_index[1],top=open[1],right=bar_index+lenght,bottom=lowest(low,1),

  border_color=color.blue,border_width=3,bgcolor=na)

  alert(“Bullish OB”,alert.freq_once_per_bar_close)

  //Bearish VEL

  if (close[1] – open[1]) > atrc*atr(10) and open – close > atrct*(close[1] – open[1])

  box.new(left=bar_index[1],top=highest(high,1),right=bar_index+lenght,bottom=open[1],

  border_color=color.red,border_width=3,bgcolor=na)

  alert(“Bearish OB”,alert.freq_once_per_bar_close)



  Msport71

  Participant

  Topics: 46

  Replies: 100

  Been thanked: 3 times
  10/13/2023 at 6:05 AM #222380
  robertogozzi

  Eccolo:

  // Auto Order Block by D. Brigaglia // // https://it.tradingview.com/script/i3BKmxdj/ // This source code is subject to the terms of the Mozilla Public License 2.0 at https://mozilla.org/MPL/2.0/ // © dadoesploso // @version=4 // // This indicator finds trend following engulfings, and draws order blocks based on the 1st candle's // range (the first candle of the engulfing pattern). // It does filter the trend with simple moving averages of 21 and 55 periods, but it doesn't filter // for retracements in the trend (you should consider only the order blocks that are coming from // engulfings after a retracement) // ONCE atrc = 0.9 ONCE atrct = 2.0 ONCE length = 350 Atr10 = AverageTrueRange[10](close) // IF ((open[1] - close[1]) > (atrc * atr10)) AND ((close - open) > (atrct * (open[1] - close[1]))) THEN DrawRectangle(BarIndex[1],open[1],BarIndex + length,lowest[1](low)) coloured("Blue",255) ENDIF // IF ((close[1] - open[1]) > (atrc * atr10)) AND ((open - close) > (atrct * (close[1] - open[1]))) THEN DrawRectangle(BarIndex[1],highest[1](high),BarIndex + length,open[1]) coloured("Red",255) ENDIF // RETURN

  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27

  // Auto Order Block by D. Brigaglia // // https://it.tradingview.com/script/i3BKmxdj/ // This source code is subject to the terms of the Mozilla Public License 2.0 at https://mozilla.org/MPL/2.0/ // © dadoesploso // @version=4 // // This indicator finds trend following engulfings, and draws order blocks based on the 1st candle's // range (the first candle of the engulfing pattern). // It does filter the trend with simple moving averages of 21 and 55 periods, but it doesn't filter // for retracements in the trend (you should consider only the order blocks that are coming from // engulfings after a retracement) // ONCE atrc   = 0.9 ONCE atrct  = 2.0 ONCE length = 350 Atr10       = AverageTrueRange[10](close) // IF ((open[1] - close[1]) > (atrc * atr10)) AND ((close - open) > (atrct * (open[1] - close[1]))) THEN    DrawRectangle(BarIndex[1],open[1],BarIndex + length,lowest[1](low)) coloured("Blue",255) ENDIF // IF ((close[1] - open[1]) > (atrc * atr10)) AND ((open - close) > (atrct * (close[1] - open[1]))) THEN    DrawRectangle(BarIndex[1],highest[1](high),BarIndex + length,open[1]) coloured("Red",255) ENDIF // RETURN





  robertogozzi

  Moderator

  Topics: 69

  Replies: 17131

  Been thanked: 4030 times
  10/13/2023 at 8:39 AM #222385
  Msport71

  Grazie e mille !



  Msport71

  Participant

  Topics: 46

  Replies: 100

  Been thanked: 3 times
